Charlotte Pipe PVC-7300-3X20 11789
  1. pin-int

Charlotte Pipe PVC-7300-3X20 11789

Charlotte Pipe PVC-7300-3X20 Foam Core Pipe, 3 in Nominal Pipe, Plain End, 3-1/2 in OD, 20 ft, SCH 40, PVC, White

  • Manufacturer: Charlotte Pipe and Foundry
  • Brand Name: Charlotte Pipe
  • Part#: 11789
  • MPN: PVC-7300-3X20
  • UPC: 611942039524
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading

PVC SCH 40 is highly durable, with high tensile and impact strength. It is easy to install and has better sound deadening qualities than PVC SCH 40 DWV foam core. Installation requires the use of primer and solvent cement. For pressure applications, sharply angled pressure fittings must be used.

Charlotte Pipe Foam Core Pipe, 3 in Nominal Pipe, Plain End Connection, 3-1/2 in Outside Diameter, 20 ft Length, 0.22 in Wall Thickness, SCH 40, Material Standard: ASTM D1785, D2665, PVC, White, 140 deg F, Domestic/Import: Domestic

Color      :      White
Connection Type      :      Plain End
Domestic/Import      :      Domestic
Length      :      20 ft
Material Standard      :      ASTM D1785, D2665
Material      :      PVC
Nominal Pipe Size      :      3 in
Outside Diameter      :      3-1/2 in
Pressure Rating      :      260 psi
Schedule Rating      :      SCH 40
Temperature Rating      :      140 deg F
Wall Thickness      :      0.22 in
  • For non-pressure systems where temperatures will not exceed 140 deg F
  • Co-extruded and has a cellular core
  • PVC SCH 40 foam core is lightweight, non-toxic and easy-to-install
  • For DWV purposes only
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Charlotte_Pipe_PVC_7112_20_Catalog.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Charlotte_PVC_7112_1_1_2X10_Specification_Sheet.pdf
