Broan-NuTone® 671 8115

Broan-NuTone 671 Bath Fan, 120 V, 1.15 A, Steel Housing, Galvanized Housing

  • Manufacturer: Madison Air
  • Brand Name: Broan-NuTone®
  • Part#: 8115
  • MPN: 671
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading

Broan-NuTone® Bath Fan, 120 V, 1.15 A, 60 Hz, Wall/Ceiling Mounting, 9 in L x 9-1/4 in W Grille, 3 in Duct, 70 cfm at 0.1 in, 1 Phase, 7-1/4 in Overall Length, 7-1/2 in Overall Width, 3-5/8 in Overall Height, Steel Housing, Galvanized Housing, White Housing

Amperage Rating      :      1.15 A
CFM Rating      :      70 cfm at 0.1 in
Color      :      White
Duct Size      :      3 in
Finish      :      Galvanized
Frequency Rating      :      60 Hz
Grille Size      :      9 in L x 9-1/4 in W
Height      :      3-5/8 in
Housing Color      :      White
Housing Finish      :      Galvanized
Housing Material      :      Steel
Length      :      7-1/4 in
Material      :      25 ga Steel
Mounting Type      :      Wall/Ceiling
Overall Height      :      3-5/8 in
Overall Length      :      7-1/4 in
Overall Width      :      7-1/2 in
Phase      :      1
Voltage Rating      :      120 V
Width      :      7-1/2 in
  • Bath Fan
  • Plug-in, permanently lubricated, Broan designed polymeric blower wheel, snap in or out motor assembly for easy cleaning no screws to drive or drop motor
  • Horizontal discharge
  • Torsion spring grille-mounting - no tools necessary
  • Double strength-mounting flanges with keyhole slots, removable wiring cover - make connections away from tight corners, no electrical knockout to remove
  • Polymeric duct fitting with tapered sleeve for easy, positive duct connection
  • For model 57V (ivory) or 57W (white), electronic variable speed control, model 59V or 59W 60 min time control, model 61V or 61W 15 min time control
