Broan-NuTone® 403001 8146

Broan-NuTone® 40000 Series 403001 Under Cabinet Range Hood, 30 in L, 17-1/2 in D, 1 -Lamp, Incandescent Light

  • Manufacturer: Madison Air
  • Brand Name: Broan-NuTone®
  • Part#: 8146
  • MPN: 403001
  • UPC: 026715010813
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading

The Broan 40000 Series is made for a wide range of installations and comes in a variety of appliance matching colors. The durable under cabinet hood installs as 3-1/4 x 10 in ducted opening only and ducts either vertically or horizontally. The hood is equipped with a 210 Max blower cfm designed for years of trouble-free service, an easy-to clean grease filter, a protective lamp lens that distributes light evenly over the cook-top and control switches for fan speed and light activation. Includes duct adapter with built-in damper.

Broan-NuTone® Under Cabinet Range Hood, 40000 Series, 120 V, 2 A, 240 W, Fan Control Type: Rocker Switch, Incandescent Light, 1 Lamp, Ducted Vent, 3-1/4 in H x 10 in W Duct, 210 cfm Flow Rate, 6.5 sones, Steel, White, 30 in Length, 17-1/2 in Depth, 6 in Height, Additional Information: 2-Speed

Additional Information      :      2-Speed
Amperage Rating      :      2 A
Color      :      White
Depth      :      17-1/2 in
Duct Size      :      3-1/4 in H x 10 in W
Fan Control Type      :      Rocker Switch
Flow Rate      :      210 cfm
Height      :      6 in
Length      :      30 in
Light Type      :      Incandescent
Material      :      Steel
Number of Lamps      :      1
Power Rating      :      240 W
Series      :      40000 Series
Sones      :      6.5 sones
Vent Type      :      Ducted
Voltage Rating      :      120 V
  • Under Cabinet Range Hood
  • Externally vented range hood offers reliable performance for your cooking needs
  • Simple to use rocker fan switch and separate rocker light switch offer easy control
  • Two speeds fan helps you tackle a variety of venting jobs
  • 210 MAX blower cfm fan helps quickly remove smoke and cooking odors from the air
  • Aluminum mesh filter is removable and dishwasher safe for easy cleaning and maintenance
  • Uses up to a 75 W in incandescent light to brightly illuminate the cooking area (bulb sold separately)
  • Installs as 3-1/4 in x 10 in ducted with included duct connector and built-in damper
  • Mitered sides and hemmed bottom for safety and good looks
  • UL listed and HVI-2100 certified for your safety and protection
  • Range hood is installed as hardwired or with an optional power cord kit (SHCK44, sold separately)
