VBF-72-A Vacuum Breaker Trap Primer. The Sloan® VBF-72-A Vacuum Breaker Trap Primer provides for a constant water seal in floor drains. Maintaining a trap seal prevents objectionable sewer gases from escaping into the air. Each time the Sloan® Flushometer is activated, a small amount of water is diverted to the floor drain (piping from Trap Primer to floor drain not supplied by Sloan). The VBF-72-A uses a patented Water Deflector that carefully regulates the amount of water diverted to the drain. This makes the VBF-72-A specially suited for use with both 1.6 gpf (6.0 Lpf) Low Consumption and 3.5 gpf (13.2 Lpf) Water Saver Flushometers.
Sloan® Vacuum Breaker Trap Primer With Fittings, 1.6 gpf Gallons per Flush, Finish: Chrome-Plated, 1-1/2 in Diameter, 13-1/2 in Length, For Use With: 113/113-1.6 Model Royal®/Regal® Flushometers, Additional Information: VBF-72-A1 Model
| Additional Information | : | VBF-72-A1 Model |
| Connection Type | : | IPS x Tube |
| Diameter | : | 1-1/2 in |
| Finish | : | Chrome-Plated |
| Flow Rate | : | 1.6 gpf |
| Gallons per Flush | : | 1.6 gpf |
| Length | : | 13-1/2 in |
| Model | : | VBF-72-A1 |
| Nominal Size | : | 1/2 x 3/8 in |
| Suitable For Use With | : | 113/113-1.6 Model Royal®/Regal® Flushometers |
- One Piece, Chrome Plated Flush Connection
- Water Deflector to control the amount of water diverted from the flush
- 3/8" Elbow and Flex-bend Tube connection from Vacuum Breaker to wall
- Diverter Wall Flange and Fittings
- Chrome Plated Wall Flange and Fitting to connect 1/2" NPT pipe
- High Back Pressure Vacuum Breaker
- One-piece Bottom Hex Coupling Nut
Specification Sheet
