Siemens Low Voltage Molded Case Circuit Breaker, 70 A, 240 VAC, 50/60 Hz, 10 kA Interrupt Rating, 3 Poles, 3 ph Phase, Bolt-On Connection, BL Frame, Thermal Magnetic Trip, Load Side Lug Terminal, Toggle Actuator, 8 to 2 AWG, 8 to 4 AWG Wire, Panel Mounting, 40 deg C, 4-1/2 in Width, 3.7 in Length, 12.8 in Height
| Actuator Type | : | Toggle |
| Amperage Rating | : | 70 A |
| Connection Type | : | Bolt-On |
| Frame Type | : | BL |
| Frequency Rating | : | 50/60 Hz |
| Height | : | 12.8 in |
| Interrupt Rating | : | 10 kA |
| Length | : | 3.7 in |
| Mounting Type | : | Panel |
| Number of Poles | : | 3 |
| Phase | : | 3 ph |
| Temperature Rating | : | 40 deg C |
| Terminal Type | : | Load Side Lug |
| Trip Type | : | Thermal Magnetic |
| Voltage Rating | : | 240 VAC |
| Width | : | 4-1/2 in |
| Wire Size | : | 8 to 2 AWG, 8 to 4 AWG |
