Decora® Wall Outlet USB Charger, 125 VAC, 5 VDC, 15 A, 1/2 hp, 2 Poles, Type-A USB, 14 to 12 AWG Conductor, Back Wired, Side Wired Terminal, Grounding Grounding, Commercial, Residential Grade, NEMA Rating: NEMA 5-15R, Thermoplastic Housing, White Housing, -10 to 40 deg C, 4.04 in Length, 1.73 in Width, 1.68 in Height
| Amperage Rating | : | 15 A |
| Conductor Size | : | 14 to 12 AWG |
| Grade | : | Commercial, Residential |
| Grounding | : | Grounding |
| HP Rating | : | 1/2 hp |
| Height | : | 1.68 in |
| Housing Color | : | White |
| Housing Material | : | Thermoplastic |
| Length | : | 4.04 in |
| NEMA Rating | : | NEMA 5-15R |
| Number of Poles | : | 2 |
| Temperature Rating | : | -10 to 40 deg C |
| Terminal Type | : | Back Wired, Side Wired |
| USB Type | : | Type-A |
| Voltage Rating | : | 125 VAC, 5 VDC |
| Width | : | 1.73 in |
- Type-A/type-A outlet charger smart chip recognizes and optimizes the charging requirements of individual devices
- Tamper-resistant receptacle
- Smart chip recognizes and optimizes the charging requirements of individual devices
- Tested to withstand over 10000 insertions
- Fits in a standard wall box, is compatible with standard wallplates and can be multi-ganged with other devices
- Easy-to-install
- Can replace existing outlets
- No data transfer capability
- Compatible with Decora® wallplates and Decora Plus™ screwless wallplates
- 3.1, 3.0, 2.0, 1.1 USB cable compatibility
