Siemens, 42EG35AF, Definite Purpose, 120 V Coil, 60 A Maximum Load Current, 3 Pole, A2L Enclosure
| Ambient Temperature | : | 158 Degrees F |
| Depth | : | 3.11 in |
| Height | : | 4.04 in |
| Weight | : | 1.59 lb |
| Width | : | 2.87 in |
- Touch protection against electrical shock: Not finger-safe
- Number of poles for main current circuit: 3
- Size of contactor: 60A
- number of NO contacts for main contacts 3
- Operating voltage for main current circuit at AC at 60 Hz maximum: 600 V
- Operational current at AC at 600 V rated value: 240 A
- Mechanical service life (operating cycles) of the main contacts typical: 250000
