Southwire® SIMpull THHN Wire, 600 V, 30 A, 10 AWG Conductor, Soft Drawn Copper Conductor, 161 mil OD, 500 ft L, 20 mil Thick Insulation, Solid, PVC Insulation, Nylon Jacket, Blue Jacket, 4 mil Jacket Thickness, 90 deg C, Spool
| Amperage Rating | : | 30 A |
| Conductor Material | : | Soft Drawn Copper |
| Conductor Size | : | 10 AWG |
| Insulation Material | : | PVC |
| Insulation Thickness | : | 20 mil |
| Jacket Color | : | Blue |
| Jacket Material | : | Nylon |
| Jacket Thickness | : | 4 mil |
| Length | : | 500 ft |
| Outside Diameter | : | 161 mil |
| Package Type | : | Spool |
| Solid/Stranded | : | Solid |
| Temperature Rating | : | 90 deg C |
| Voltage Rating | : | 600 V |
Specification Sheet
