Broan-NuTone® Utility Ventilation Fan, 120 VAC, 1.5 A, 60 Hz, Steel, Plastic, White, Wall Mount, 8-3/8 in Width, 11-1/2 in L x 11-1/2 in W Grille, 180 cfm, 8-3/8 in Dia Duct, 1925 rpm Speed Rating
| Amperage Rating | : | 1.5 A |
| CFM Rating | : | 180 cfm |
| Color | : | White |
| Duct Size | : | 8-3/8 in Dia |
| Frequency Rating | : | 60 Hz |
| Grille Size | : | 11-1/2 in L x 11-1/2 in W |
| Material | : | Steel, Plastic |
| Mounting Type | : | Wall |
| Speed Rating | : | 1925 rpm |
| Voltage Rating | : | 120 VAC |
| Width | : | 8-3/8 in |
- Utility Ventilation Fan
- Efficient ventilation for a variety of applications
- Contemporary-styled grille complements modern decor
- White polymeric grilles can be painted to match any decor
- Permanently lubricated, thermally protected, plug-in motor
- Rugged steel housing with modern profile on outer weather hood
- Ventilator shall be steel housing finished with electrically-bonded epoxy paint
- Specially designed polymeric fan blade
- Motor assembly offers fast, easy "twist-lock" installation
- Housing adjusts to fit walls from 4-1/2 - 9-1/2 in thick
- Built-in backdraft damper
- Long-lasting electrically bonded epoxy coating can be painted to match outdoor styling
- Built-in rotary switch on model 509S no wall switch to wire
- 6.5 sones sound
- Eliminate humidity from laundry rooms, tobacco smoke from recreation rooms and workshops or cooking fumes from kitchens with Broan's high-efficiency utility ventilators
